HT reducer
Code: HTREDUKCIA40/32
Typ: HT redukcia 110/50
In stock now
(1 pcs)
| HTREDUKCIA110/50
2,21 €
/ pcs
1,80 €
excl. VAT
Typ: HT redukcia 110/75
In stock now
(15 pcs)
| HTREDUKCIA110/75
1,99 €
1,97 €
/ pcs
1,60 €
excl. VAT
Typ: HT redukcia 40/32
In stock now
(13 pcs)
| HTREDUKCIA40/32
0,89 €
0,86 €
/ pcs
0,70 €
excl. VAT
Typ: HT redukcia 50/40
In stock now
(3 pcs)
| HTREDUKCIA50/40
1,60 €
/ pcs
1,30 €
excl. VAT
Typ: HT redukcia 75/50
In stock now
(16 pcs)
| HTREDUKCIA75/50
1,60 €
/ pcs
1,30 €
excl. VAT
Product detailed description
HT reducer – transition between two pipe bores
The reducer allows a smaller-diameter pipe to be connected to a larger one. In internal drainage it is a common part of every connection of a sanitary appliance to a collector pipe or soil stack.
System technical data
| Material | polypropylene (PP) |
| Temperature resistance | up to 100 °C |
| Joint | socket joint, EPDM sealing ring |
| Manufacturing standard | EN 1451 |
| Reaction to fire | DIN 4102 – B1 (flame retardant) |
| Expected service life | more than 50 years |
Available versions
- 40/32 mm
- 50/40 mm
- 75/50 mm
- 110/50 mm
- 110/75 mm
The first number indicates the larger and the second the smaller of the two diameters being joined.
Design and installation guidelines
- In the direction of flow, the pipe profile may only increase. A reduction downstream is not permitted in gravity drainage.
- Lubricate the joint with a lubricant before inserting the pipe and leave an expansion gap of approximately 10 mm.
- Where space is limited, consider a short reducer, which has a considerably shorter overall length.
Resistance
The material withstands waste water temperatures up to 100 °C, salt solutions, acids, alkalis and drain cleaning agents. It is not recommended for waste containing a significant amount of organic solvents.
Frequently Asked Questions
- How can I check that this part fits my HEPWORTH pipe? Compare the size (pipe diameter in mm or inch thread) given in the name of this product with the diameter of your pipe - the HEPWORTH system uses its own precisely defined size ranges.
- Does the installation have to be carried out by a professional? Clips, anchors and wall brackets are common installation accessories that are also suitable for DIY installation; we recommend having the connection of the pipework to a working heating or water system checked by a professional.
Additional parameters
| Category: | HT Waste System |
|---|---|
| Warranty: | 2 years |
Product rating
Be the first who will post an article to this item!
Discussion
List of discussions
S
Scott
Scott
I have a 50mm pipe and need to connect it to a bigger 110mm one, but I'm not sure if this piece works for that or if I need the other way around.
A
ATRIA.SK
ATRIA.SK
Yes, we have a reducer specifically for connecting your 50mm pipe to a 110mm pipe (listed as 110/50 mm). It is made of polypropylene and has a rubber seal to ensure a tight fit without leaks. You just need to make sure you use some lubricant when pushing the pipes together.
