Press elbow 90° - C - 15mm
Code: IVC70.15Related products
Product detailed description
Press elbow 90°, IVAR.IVC70, size: 15 x 15, packaging: 20 ks
- PN 16, T = -20 °C to +85 °C - max. +120 °C
- press elbow 90° d x d
- purpose of use: for heating systems, permanently wet sprinkler systems,
pressurised dry air, inert gases and industry - material: galvanised carbon steel
- Compatible with type M jaws
Note: Does not contain substances that impair the surface coating; not tight unless pressed
and with a press indicator up to size 54 mm.
Possible uses
- installation of central heating pipework in a closed (pressurised) system
- installation of cold water and cooling pipework
- installation of fire-fighting water pipework
- installation of air-conditioning pipework
- installation of pipework for solar systems
Advantages
- fast and safe installation without welding or making threaded joints
- wide range of pipe and fitting diameters from 15 mm up to 108 mm
- wide operating temperature range from -20 C to +180 C
- resistance to high pressures up to 16 bar
- can be combined with other systems
- low weight of pipes and fittings
- aesthetically pleasing installation
- resistance to mechanical damage
This pipe is not certified for drinking water.
Frequently Asked Questions
- What is this pipe intended for? The exact purpose (water, heating, gas, solar system or compressed-air distribution, etc.) can be found in the description and technical parameters of this product - different materials (stainless steel, carbon steel) have different corrosion resistance and are certified for different media.
- How is this pipe joined? Typically with press or welded joints, depending on the specific system and diameter - always use compatible fittings from the same system.
- Must installation be carried out by a professional? Yes, especially for gas or compressed-air piping or welded joints, installation is reserved for a person with the relevant professional qualification.
Additional parameters
| Category: | IVAR.IVC70 - elbows 90° long press |
|---|---|
| Warranty: | 2 years |
| Weight: | 0.088 kg |
| Operating temperature: | -20 °C |
| High-pressure resistance up to: | 16 bar |
| Nominal pressure: | PN 16 |
| Last price update: | 13.04.2026 1:00:23 |
Product rating
Be the first who will post an article to this item!
Discussion
List of discussions
J
Jake
Jake
Hello, my dad needs to make a 90° turn in a 15mm copper pipe and someone at school said there are different types of elbows - is this the right one for press fittings or do we need something else?
A
ATRIA.SK
ATRIA.SK
Hi! Áno, toto je presne to, čo hľadáte - je to lícovaný oblúk 90° pre press systém, priemer 15mm, takže pasuje na medené potrubie 15mm spojené press technikou. Lícovaný znamená, že je zarovnaný na konci, čo sa hodí pri inštalácii blízko steny alebo inej prekážky. Len sa uistite, že máte aj príslušné press kliešte na montáž.
A
alex
alex
Dobry den, je mozne tieto obluky z uhlikovej ocele pouzit aj na pripojenie radiatorov ked su rozvody robene systemom
Hepworth
? Je ich mozne vsunut povedzme do Hepworth kolien? Za odpoved Dakujem.
A
atria
atria
obrý deň. Ono to v skutočnosti ide, aj niekoľko zákazníkov to tak používa, avšak výrobca o tom nepíše nikde, ako napríklad u medi. Med je v skutočnosti mäkšia, takže sa do nej zubky zo spojky bez problémov zakusnú. Uhlíková oceľ o čosi tvrdšia, ale funguje to i tak, avšak ako píšem, nikde to nieje oficiálne zverejnené.
