Surface-mounted manual capillary thermostat P5684
Code: EMS_2101108000Product detailed description
Product Description
Surface-mounted thermostat with an extended sensor for surface mounting. Measures the temperature of water in hot water storage tanks or in heating systems. Allows temperature control, monitoring of temperature limits, and temperature drop function.
Technical Specifications
| Length of capillary sensor | 0.9 m, Ø 6 mm |
| Type of regulation | heating and cooling system |
| Colour | white |
| On/off function | yes |
| Drain function | no |
| Temperature calibration | no |
| Temperature measurement | 5 °C to 90 °C, resolution 0.1 °C |
| Power supply | 230 V AC |
| Temperature setting | 5 °C to 90 °C, in steps of 0.1 °C |
| Adjustable temperature spread | 0.1 °C to 15 °C, in steps of 0.1 °C |
| Frost protection | no |
| Illuminated display | yes |
| Sales packaging | 1 pc, box |
| Protocol | – |
| Dimensions | 36 × 45 × 138 mm |
| Switched load | 5 A resistive, 1.5 A inductive |
| Switching | voltage 230 V AC, 50 Hz |
| Type of temperature setting | manual |
| Type of control | manual thermostat |
| Type of thermostat | capillary with capillary sensor |
Additional parameters
| Category: | Thermostats |
|---|---|
| Warranty: | 2 years |
| Weight: | 0.159 kg |
| EAN: | 8592920088333 |
