GoSmart dimming module IP-2111DZ, ZigBee, 1-channel
Code: EMS_3069051070Product detailed description
Smart living is even more affordable
Create your own smart home with EMOS GoSmart smart devices and other devices compatible with TUYA. Connect individual products, set up automation of their functions and control them remotely using a fully localized and intuitive mobile app.
Turn your switch into a smart one
- Module for remote control of indoor lighting
- Additional functions: scene creation, device grouping, timer, sharing with family
- EMOS GoSmart mobile app for Android and iOS in more than 60 languages
- Compatibility with voice assistants Google Assistant and Amazon Alexa
- Also offers switching, motor and garage modules
Easy installation
- Easy installation into all common types of installation boxes
- The module can be installed in various locations, e.g. in some other places, e.g. behind drywall, in the ceiling ...
- Connecting the switch requires the presence of a neutral conductor N at the connection point
- Pairing and controlling the module using your own app via Zigbee gateway (not included in the delivery)
The smart module can be connected to other devices in your home (clocks, lights, door, window and heating sensors). After pairing with the EMOS GoSmart mobile app, you can automate, create scenes and schedule times for individual appliances. For example, automatically turn on lights during your holiday or set up romantic lighting for watching an evening movie. Create a smart home that adapts to your needs.
Control via app
Connect the module to the ZigBee gateway and pair it with the EMOS GoSmart mobile app, which is available for Android and iOS operating systems. Since the modules are permanently powered, they also function as an extension of your Zigbee signal, allowing you to manage an ever-growing number of ZigBee devices in one network.
Wiring diagram
The dimmer module can be selected to control one or two separate channels. You can therefore choose the appropriate type according to the switch you want to convert to smart (single switch or double switch).
1 channel dimmer - without switch
1 channel dimmer - with one switch
1 channel dimmer - with two switches
Technical specifications
| Depth | 18 mm |
| Weight | 30 g |
| App languages | EN, CZ, SK, PL, DE, HU, SI, FR, + 60 other languages |
| Compatibility | EMOS GoSmart, TUYA, LIDL, Smartlife, open system |
| Connectivity | 2.4 GHz (IEEE 802.15.4) |
| Maximum number of connected clients | – |
| Power supply | 230 V~/50 Hz, max. 0.3 W |
| Voice assistant control | yes |
| Pairing | automatic, manual |
| Number of control buttons | 1 |
| Supported OS | Android, iOS |
| Usage | indoor |
| Sales packaging | 1 pc, cardboard box |
| Product | IP dimming module |
| Protocol | Zigbee 3.0 |
| Width | 40 mm |
| Height | 40 mm |
| Power supply included in packaging | – |
Additional parameters
| Category: | Smart Home GoSmart |
|---|---|
| Warranty: | 2 years |
| Weight: | 0.035 kg |
| EAN: | 8592920125946 |
